Overview
LF DriverFRWS series
Visaton
Visaton FRWS 5
Visaton FRWS 5 is a 2" 8 ohm LF driver rated at 4W RMS. The validated T/S data includes Fs 250Hz, Qts 1.63, Vas 0.1L, Xmax 2mm, sensitivity 78.9dB, plus 2cm³ Vd and 78 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £10.26.
Size
2"
Impedance
8Ω
RMS Power
4W
Sensitivity
78.9dB
84.0dBmanufacturer; using T/S-derived value (5.1dB delta).
EBP
78
Either alignment
Vd
2cm³
T/S Parameters
Valid
Fs250Hz
Qts1.63
Qes3.22
Qms3.3
Vas0.1L
Re6.8Ω
Le0.10mH
BL1.4Tm
Sd12cm²
Mms1g
Xmax2.0mm
SPL79dB
Power4W
Impedance8Ω
F Low150Hz
F High20000Hz
Xover250Hz
Voice Coil14mm
Flux Density0.75T
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorpartsexpress
Updated 11 Sept 2026· 8Ω
Source: ex VAT
£10.60
inc VAT
16 in stock
Best current price
Updated 11 Sept 2026
partsexpress
£10.26
Avg £10.43£0.17 below avg (-1.6%)
inc VAT·4 in stock
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.1kg
Diameter50.0mm
Cutout Diameter45.0mm
