Overview
LF Driver
Sica
Sica 2 H 0.8 SL
Sica 2 H 0.8 SL is a 2" 8 ohm LF driver rated at 20W RMS. The validated T/S data includes Fs 216Hz, Qts 0.81, Vas 0.1L, Xmax 1.4mm, sensitivity 82.1dB, plus 2cm³ Vd and 216 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
2"
Impedance
8Ω
RMS Power
20W
Sensitivity
82.1dB
84.1dBmanufacturer; using T/S-derived value (2.0dB delta).
EBP
216
Vented alignment
Vd
2cm³
T/S Parameters
Valid
Fs216Hz
Qts0.81
Qes1.00
Qms2.8
Vas0.1L
Re5.5Ω
Le0.20mH
BL2.6Tm
Sd11cm²
Mms1g
Xmax1.4mm
SPL82dB
Power20W
Impedance8Ω
Voice Coil20mm
Flux Density1.30T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.1kg
Diameter52.5mm
Overall Depth32.5mm
Cutout Diameter48.0mm
Bolt Circle Diameter61.5mm
