REDCATT 32NFR 8Ω
8 Ω
No current price
- Fs
- 118Hz
- Xmax
- 1.2mm
- SPL
- 89dB
- Pe
- 30W
- BL
- 5.3T·m
- Vd
- 4cm³
- Qts
- 0.32
- Vas
- 1L
REDCATT 32NFR is a 3-inch 8 ohm LF driver rated at 30 W RMS. The validated T/S data includes Fs 118 Hz, Qts 0.32, Vas 1.1 L, Xmax 1.2 mm, sensitivity 89.3 dB, plus 4 cm³ Vd and 337 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 118Hz
- Qts
- 0.32
- Qes
- 0.35
- Qms
- 3.9
- Vas
- 1.1L
- Re
- 5.5Ω
- Le
- 0.20mH
Motor and cone
- BL
- 5.3T·m
- Sd
- 33cm²
- Mms
- 2g
- Xmax
- 1.2mm
- Vd †
- 4cm³
- Voice coil
- 19mm
Power and response
- Sensitivity †
- 89.3dB
- Manufacturer sensitivity
- 91dB
- Power
- 30W
- Impedance
- 8Ω
- EBP †
- 337 · Leans vented
Size and mounting
- Diameter
- 82.5mm
- Cutout
- 70.5mm
- Bolt circle
- 84mm
- Weight
- 0.24kg
Other published values
- Xmech
- 5.2
- Power Peak
- 120
Other dimensions
- Mounting Depth
- 45
Sensitivity shows 89.3 dB, calculated from the T/S values. REDCATT publishes 91.0 dB, 1.7 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else REDCATT lists
LF · Primary · 3″
- BL
- 5.3T·m
- Fs
- 118Hz
- Le
- 0.20mH
- Re
- 5.5Ω
- Sd
- 33cm²
- Mms
- 2g
- Qes
- 0.35
- Qms
- 3.9
- Qts
- 0.32
- SPL
- 89.3dB
- Vas
- 1.1L
- Xmax
- 1.2mm
- Xmech
- 5.2
- Power
- 30W
- Impedance
- 8Ω
- Power Peak
- 120
- Sensitivity
- 91dB
- Calculated sensitivity †
- 89.3dB
- Manufacturer sensitivity
- 91dB
- Voice coil
- 19mm
- Weight
- 0.24kg
- Diameter
- 82.5mm
- Mounting Depth
- 45
- Cutout
- 70.5mm
- Bolt circle
- 84mm
