Monacor TF1225/8
Monacor TF1225/8 is a 12" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 56Hz, Qts 0.37, Vas 67.3L, Xmax 4.5mm, sensitivity 96.4dB, plus 239cm³ Vd and 132 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
250W
Sensitivity
96.4dB
EBP
132
Vented alignment
Vd
239cm³
T/S Parameters
Valid
Fs56Hz
Qts0.37
Qes0.42
Qms3.1
Vas67.3L
Re5.1Ω
Le0.86mH
BL14.3Tm
Sd531cm²
Mms49g
Xmax4.5mm
SPL96dB
Power250W
Impedance8Ω
F Low50Hz
F High4000Hz
Voice Coil64mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.1kg
Diameter309.0mm
Overall Depth130.0mm
Cutout Diameter283.0mm
