Overview
LF DriverTF series
Monacor
Monacor TF1230S/8
Monacor TF1230S/8 is a 12" 8 ohm LF driver rated at 300W RMS. The validated T/S data includes Fs 60Hz, Qts 0.37, Vas 54.4L, Xmax 4.5mm, sensitivity 96.5dB, plus 239cm³ Vd and 143 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
300W
Sensitivity
96.5dB
EBP
143
Vented alignment
Vd
239cm³
T/S Parameters
Valid
Fs60Hz
Qts0.37
Qes0.42
Qms3.3
Vas54.4L
Re6.0Ω
Le0.98mH
BL16.6Tm
Sd531cm²
Mms51g
Xmax4.5mm
SPL97dB
Power300W
Impedance8Ω
F Low50Hz
F High4000Hz
Voice Coil75mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.3kg
Diameter317.5mm
Overall Depth137.0mm
Cutout Diameter283.0mm
