12-inch LF driver · LEGEND EM series · 200 W

Eminence LEGEND EM12 8Ω

Name: Eminence LEGEND EM12 8 Ohm
Brand: Eminence
SKU: LEGEND EM12

8 Ω · 60–4900 Hz

No price for delivery to the UK

All 1 offer

Open in 00 Simulator

Fs: 49Hz
Xmax: 1.3mm
SPL: 98dB
Pe: 200W
BL: 16.9T·m
Vd: 68cm³
Qts: 0.28
Vas: 102L

See all 23 specs

Specifications

Published by Eminence

Manufacturer page

Eminence LEGEND EM12 is a 12-inch 8 ohm LF driver rated at 200 W RMS. The validated T/S data includes Fs 49 Hz, Qts 0.28, Vas 102.3 L, Xmax 1.3 mm, sensitivity 98.2 dB, plus 68 cm³ Vd and 169 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.

The published T/S values agree with each other

Thiele/Small

Fs: 49Hz
Qts: 0.28
Qes: 0.29
Qms: 7.4
Vas: 102.3L
Re: 6.6Ω
Le: 0.49mH

Motor and cone

BL: 16.9T·m
Sd: 532cm²
Mms: 40g
Xmax: 1.3mm
Vd †: 68cm³

Power and response

Sensitivity †: 98.2dB
Manufacturer sensitivity: 101.1dB
Power: 200W
Impedance: 8Ω
Range: 60–4900Hz
EBP †: 169 · Leans vented

Size and mounting

Diameter: 314.5mm
Cutout: 281.2mm
Depth: 136.7mm
Weight: 7.4kg

Other published values

Cms: 0.26mm/N

Sensitivity shows 98.2 dB, calculated from the T/S values. Eminence publishes 101.1 dB, 2.9 dB apart.

† Calculated by bits from the published values

What this validation status means

Everything else Eminence lists

LF · Primary · 12″

BL: 16.9T·m
Fs: 49Hz
Le: 0.49mH
Re: 6.6Ω
Sd: 532cm²
Cms: 0.26mm/N
Mms: 40g
Qes: 0.29
Qms: 7.4
Qts: 0.28
SPL: 98.2dB
Vas: 102.3L
Xmax: 1.3mm
Power: 200W
Impedance: 8Ω
Sensitivity: 101.1dB
Low limit: 60Hz
Calculated sensitivity †: 98.2dB
High limit: 4900Hz
Manufacturer sensitivity: 101.1dB
Weight: 7.4kg
Diameter: 314.5mm
Depth: 136.7mm
Cutout: 281.2mm
