LF DriverALPHA series
Eminence
Eminence ALPHA 3-32
Eminence ALPHA 3-32 is a 3" 32 ohm LF driver rated at 35W RMS. The validated T/S data includes Fs 117Hz, Qts 0.74, Vas 1.0L, Xmax 2.6mm, sensitivity 84.7dB, plus 7cm³ Vd and 138 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £21.47.
Size
3"
Impedance
32Ω
RMS Power
35W
Sensitivity
84.7dB
88.0dBmanufacturer; using T/S-derived value (3.3dB delta).
EBP
138
Vented alignment
Vd
7cm³
T/S Parameters
Valid
Fs117Hz
Qts0.74
Qes0.85
Qms5.9
Vas1.0L
Re22.4Ω
Le0.23mH
BL6.5Tm
Sd29cm²
Mms2g
Xmax2.6mm
SPL85dB
Power35W
Impedance32Ω
F Low150Hz
F High20000Hz
Pricing & availability
Price definitionsPrice movement
Best current price
£21.47
inc VAT·Vendor hidden
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.4kg
Diameter101.1mm
Overall Depth44.7mm
Cutout Diameter77.2mm
Bolt Circle Diameter92.2mm
