Overview
LF DriverIB series
Acoustic Elegance
Acoustic Elegance IB18AU-4
Acoustic Elegance IB18AU-4 is a 18" 4 ohm LF driver rated at 500W RMS. The validated T/S data includes Fs 28Hz, Qts 0.60, Vas 389.8L, Xmax 18mm, sensitivity 93.3dB, plus 2192cm³ Vd and 43 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
18"
Impedance
4Ω
RMS Power
500W
Sensitivity
93.3dB
EBP
43
Sealed alignment
Vd
2192cm³
T/S Parameters
Valid
Fs28Hz
Qts0.60
Qes0.66
Qms6.0
Vas389.8L
Re2.8Ω
Le0.41mH
BL11.3Tm
Sd1218cm²
Mms170g
Xmax18.0mm
SPL93dB
Power500W
Power Nominal500W
Impedance4Ω
