Overview
LF Driver
Sica
Sica 8 H 1.5 CS
Sica 8 H 1.5 CS is a 8" 8 ohm LF driver rated at 100W RMS. The validated T/S data includes Fs 51Hz, Qts 0.72, Vas 26.9L, Xmax 4mm, sensitivity 87.7dB, plus 86cm³ Vd and 54 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
100W
Sensitivity
87.7dB
88.9dBmanufacturer; using T/S-derived value (1.2dB delta).
EBP
54
Either alignment
Vd
86cm³
T/S Parameters
Valid
Fs51Hz
Qts0.72
Qes0.94
Qms3.0
Vas26.9L
Re6.1Ω
Le1.12mH
BL7.0Tm
Sd214cm²
Mms24g
Xmax4.0mm
SPL88dB
Power100W
Impedance8Ω
Voice Coil38mm
Flux Density0.78T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.4kg
Diameter210.0mm
Overall Depth87.6mm
Cutout Diameter184.0mm
Bolt Circle Diameter197.0mm
