Overview
LF Driver
Sica
Sica 6.5 H 1.5 CP
Sica 6.5 H 1.5 CP is a 6.5" 8 ohm LF driver rated at 120W RMS. The validated T/S data includes Fs 45Hz, Qts 0.42, Vas 20.2L, Xmax 6mm, sensitivity 88.2dB, plus 74cm³ Vd and 99 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6.5"
Impedance
8Ω
RMS Power
120W
Sensitivity
88.2dB
89.4dBmanufacturer; using T/S-derived value (1.2dB delta).
EBP
99
Either alignment
Vd
74cm³
T/S Parameters
Valid
Fs45Hz
Qts0.42
Qes0.46
Qms5.2
Vas20.2L
Re6.1Ω
Le0.48mH
BL7.0Tm
Sd123cm²
Mms13g
Xmax6.0mm
SPL88dB
Power120W
Impedance8Ω
Voice Coil38mm
Flux Density0.90T
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.6kg
Diameter175.0mm
Overall Depth77.5mm
Cutout Diameter143.0mm
Bolt Circle Diameter164.2mm
