Overview
LF DriverFTX series
Monacor
Monacor FTX1025/8
Monacor FTX1025/8 is a 10" 8 ohm LF driver rated at 300W RMS. The validated T/S data includes Fs 79Hz, Qts 0.44, Vas 25.9L, Xmax 5mm, sensitivity 95.9dB, plus 173cm³ Vd and 151 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
10"
Impedance
8Ω
RMS Power
300W
Sensitivity
95.9dB
EBP
151
Vented alignment
Vd
173cm³
T/S Parameters
Valid
Fs79Hz
Qts0.44
Qes0.52
Qms2.8
Vas25.9L
Re5.4Ω
Le0.48mH
BL12.3Tm
Sd346cm²
Mms33g
Xmax5.0mm
SPL96dB
Power300W
Impedance8Ω
F Low60Hz
F High5000Hz
Voice Coil64mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.5kg
Diameter260.0mm
Overall Depth123.0mm
Cutout Diameter234.0mm
