Wavecor SW118WA01 4Ω
LF DriverMedia
Wavecor
SW118WA01
Image unavailable
Overview
LF DriverSW118WA series
Wavecor
Wavecor SW118WA01
Wavecor SW118WA01 is a 4.5" 4 ohm LF driver. The validated T/S data includes Fs 58Hz, Qts 0.39, Vas 3.3L, Xmax 4mm, sensitivity 84dB, plus 20cm³ Vd and 141 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
4.5"
Impedance
4Ω
Sensitivity
84.0dB
EBP
141
Vented alignment
Vd
20cm³
T/S Parameters
Valid
Fs58Hz
Qts0.39
Qes0.41
Qms8.4
Vas3.3L
Re3.2Ω
BL4.7Tm
Sd49cm²
Mms8g
Xmax4.0mm
SPL84dB
Impedance4Ω
Voice Coil26mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Not enough T/S data
Missing Le, RMS power
BASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Not enough T/S data
Missing Le, RMS power
VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Not enough T/S data
Missing Le, RMS power
00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Diameter114.3mm
