Tang Band W5-1611SAF
Tang Band W5-1611SAF is a 5" 6.3 ohm LF driver rated at 28W RMS. The validated T/S data includes Fs 60Hz, Qts 0.44, Vas 11.7L, Xmax 3mm, sensitivity 88.9dB, plus 28cm³ Vd and 115 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
5"
Impedance
6.3Ω
RMS Power
28W
Sensitivity
88.9dB
90.0dBmanufacturer; using T/S-derived value (1.1dB delta).
EBP
115
Vented alignment
Vd
28cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
spl240 ptsp1medium
Curve provenanceInspect 2 tracesHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
spl
Frequency response
240 plotted pointsMedium confidence1,337 selected pixels of 1,634 - Trace datasheet-response-trace-poc/v1
impedance
Impedance response
240 plotted pointsMedium confidence2,711 selected pixels of 2,812
T/S Parameters
Valid
Fs60Hz
Qts0.44
Qes0.52
Qms2.8
Vas11.7L
Re6.3Ω
Le0.02mH
BL5.5Tm
Sd94cm²
Mms6g
Xmax3.0mm
SPL89dB
Power28W
Impedance6Ω
