LF DriverCAN143 series
Lavoce
Lavoce CAN143.00T
Lavoce CAN143.00T is a 12" 8 ohm LF driver rated at 400W RMS. The validated T/S data includes Fs 44Hz, Qts 0.30, Vas 122.3L, Xmax 6mm, sensitivity 97.3dB, plus 428cm³ Vd and 142 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
400W
Sensitivity
97.3dB
99.0dBmanufacturer; using T/S-derived value (1.7dB delta).
EBP
142
Vented alignment
Vd
428cm³
Overall Parameters
Valid
Fs44Hz
Qts0.30
Qes0.31
Qms6.3
Vas122.3L
Re5.2Ω
Le0.55mH
BL18.8Tm
Sd713cm²
Mms77g
Xmax6.0mm
SPL97dB
Power400W
Impedance8Ω
Min Impedance6.2Ω
F Low45Hz
F High18000Hz
Voice Coil75mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
What this validation status meansPricing & availability
Price definitionsNo current price found
Pricing may appear after the next vendor refresh.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight5.0kg
Driver Components
LF
Fs44 Hz
Qts0.30
Qes0.31
Qms6.3
Vas122.3 L
Re5.2 Ω
Le0.55 mH
BL18.8 Tm
Sd713 cm²
Mms77 g
Xmax6.0 mm
SPL97 dB
Power400 W
Impedance8 Ω
Min Impedance6.2 Ω
F Low45 Hz
F High4500 Hz
Voice Coil75 mm
Cms0.17
Power Program800
Xmech10
Section dimensions
Weight5000.0 kg
HF
SPL106 dB
Power80 W
Impedance8 Ω
Min Impedance8.0 Ω
F Low600 Hz
F High18000 Hz
Xover1200 Hz
Throat36 mm
Voice Coil75 mm
Flux Density1.90 T
Power Program160
