Overview
LF DriverTC series
Peerless
Peerless TC8FD05-04
Peerless TC8FD05-04 is a 3" 4 ohm LF driver rated at 25W RMS. The validated T/S data includes Fs 170Hz, Qts 0.95, Vas 0.6L, Xmax 2.7mm, sensitivity 85.8dB, plus 9cm³ Vd and 143 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
3"
Impedance
4Ω
RMS Power
25W
Sensitivity
85.8dB
EBP
143
Vented alignment
Vd
9cm³
T/S Parameters
Valid
Fs170Hz
Qts0.95
Qes1.19
Qms4.5
Vas0.6L
Re3.0Ω
Le0.06mH
BL2.5Tm
Sd33cm²
Mms2g
Xmax2.7mm
SPL86dB
Power25W
Impedance4Ω
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.4kg
