Hornresp
.txt · Hornresp driver database
Driver file ready to place in Hornresp’s Drivers folder.
Download for HornrespMonacor FTR08-2011D/8 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverFTR series
Monacor
Monacor FTR08-2011D/8
Monacor FTR08-2011D/8 is a 8" 8 ohm LF driver rated at 200W RMS. The validated T/S data includes Fs 86Hz, Qts 0.43, Vas 9L, Xmax 5.5mm, sensitivity 92.6dB, plus 125cm³ Vd and 172 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
200W
Sensitivity
92.6dB
EBP
172
Vented alignment
Vd
125cm³
T/S Parameters
Valid
Fs86Hz
Qts0.43
Qes0.50
Qms2.2
Vas9.0L
Re5.8Ω
Le0.38mH
BL12.7Tm
Sd227cm²
Mms28g
Xmax5.5mm
SPL93dB
Power200W
Impedance8Ω
F Low70Hz
F High6000Hz
Voice Coil50mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.6kg
Diameter225.0mm
Overall Depth102.0mm
Cutout Diameter187.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Monacor
FTR08-2011D/8
8"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
96%
Similarity
£99.00
Celestion
FTR08-2011D
8"
Xmax5.5mm0%
Qts0.44+1%
BL12.7Tm0%
Vas9L0%
Qes0.54+8%
92%
Similarity
Monacor
TF0818/8
8"
Xmax5mm-9%
Qts0.430%
BL12.9Tm+2%
Vas9.4L+4%
Qes0.49-1%
92%
Similarity
£50.00
Celestion
TF0818
8"
Xmax5mm-9%
Qts0.430%
BL12.9Tm+2%
Vas9.4L+5%
Qes0.49-1%
84%
Similarity
£125.00
Celestion
NTR08-2011D
8"
Xmax6mm+9%
Qts0.44+1%
BL12Tm-6%
Vas10.3L+15%
Qes0.54+7%
82%
Similarity
FaitalPRO
8HX210
8"
Xmax6.5mm+19%
Qts0.44+2%
BL11.9Tm-7%
Vas10.1L+12%
Qes0.50%
81%
Similarity
BMS
8S219
8"
Xmax6.3mm+15%
Qts0.41-5%
BL13.3Tm+5%
Vas9.7L+8%
Qes0.45-10%
80%
Similarity
Celestion
CNX0820
8"
Xmax6mm+9%
Qts0.4-8%
BL12Tm-5%
Vas9.9L+10%
Qes0.45-10%
69%
Similarity
£135.13
FaitalPRO
8HX150
8"
Xmax4.9mm-11%
Qts0.41-5%
BL11.6Tm-9%
Vas13L+44%
Qes0.43-14%
69%
Similarity
£92.98
B&C
8CL51
8"
Xmax6.5mm+18%
Qts0.41-5%
BL12Tm-6%
Vas12.5L+39%
Qes0.44-12%
66%
Similarity
£407.09
Beyma
8CFX260ND
8"
Xmax6mm+9%
Qts0.35-19%
BL13.5Tm+6%
Vas8L-11%
Qes0.37-26%
66%
Similarity
£71.42
Lavoce
WAF082.00
8"
Xmax6.3mm+15%
Qts0.37-14%
BL12.5Tm-2%
Vas11.9L+32%
Qes0.41-18%
66%
Similarity
BMS
8N519
8"
Xmax6.3mm+15%
Qts0.37-14%
BL13.8Tm+9%
Vas10.9L+21%
Qes0.41-18%
