Overview
LF DriverTF series
Monacor
Monacor TF0818/8
Monacor TF0818/8 is a 8" 8 ohm LF driver rated at 100W RMS. The validated T/S data includes Fs 94Hz, Qts 0.43, Vas 9.4L, Xmax 5mm, sensitivity 94dB, plus 113cm³ Vd and 191 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
100W
Sensitivity
94.0dB
EBP
191
Vented alignment
Vd
113cm³
T/S Parameters
Valid
Fs94Hz
Qts0.43
Qes0.49
Qms3.3
Vas9.4L
Re6.7Ω
Le0.75mH
BL12.9Tm
Sd227cm²
Mms20g
Xmax5.0mm
SPL94dB
Power100W
Impedance8Ω
F Low70Hz
F High6000Hz
Voice Coil44mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight2.3kg
Diameter208.0mm
Overall Depth99.0mm
Cutout Diameter183.0mm
