Overview
LF DriverCF series
Monacor
Monacor CF0820BMB/8
Monacor CF0820BMB/8 is a 8" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 51Hz, Qts 0.37, Vas 22.4L, Xmax 7.3mm, sensitivity 90.7dB, plus 165cm³ Vd and 128 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
250W
Sensitivity
90.7dB
93.0dBmanufacturer; using T/S-derived value (2.3dB delta).
EBP
128
Vented alignment
Vd
165cm³
T/S Parameters
Valid
Fs51Hz
Qts0.37
Qes0.39
Qms5.1
Vas22.4L
Re5.5Ω
Le0.78mH
BL11.9Tm
Sd227cm²
Mms32g
Xmax7.3mm
SPL91dB
Power250W
Impedance8Ω
F Low50Hz
F High6000Hz
Voice Coil50mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight3.1kg
Diameter215.0mm
Overall Depth108.0mm
Cutout Diameter187.0mm
