Dayton Audio CE70PR-4 4Ω
4 Ω · 85–13000 Hz
£11.06
8.9%SoundImports · 7 in stock · All 2 offers
- Fs
- 109Hz
- Xmax
- 4mm
- SPL
- 82dB
- Pe
- 20W
- BL
- 3.1T·m
- Vd
- 10cm³
- Qts
- 0.63
- Vas
- 0.52L
Manufacturer response and impedance data, with source and trace details below. The left and right arrow keys read every shown curve at a frequency, a twelfth of an octave at a time, or an octave with Shift. Escape clears the reading.
Curve provenanceInspect 2 traces
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
15 degrees
Frequency response
188 plotted pointsMedium confidence1,081 selected pixels of 1,427 - Trace datasheet-response-trace-poc/v1
on-axis
Frequency response
240 plotted pointsMedium confidence3,575 selected pixels of 3,575
Dayton Audio CE70PR-4 is a 2.5-inch 4 ohm LF driver rated at 20 W RMS. The validated T/S data includes Fs 109 Hz, Qts 0.63, Vas 0.5 L, Xmax 4 mm, sensitivity 81.5 dB, plus 10 cm³ Vd and 142 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £11.06.
The published T/S values agree with each other
Thiele/Small
- Fs
- 109Hz
- Qts
- 0.63
- Qes
- 0.77
- Qms
- 3.5
- Vas
- 0.5L
- Re
- 3.1Ω
- Le
- 0.31mH
Motor and cone
- BL
- 3.1T·m
- Sd
- 25cm²
- Mms
- 4g
- Xmax
- 4mm
- Vd †
- 10cm³
Power and response
- Sensitivity †
- 81.5dB
- Manufacturer sensitivity
- 85dB
- Power
- 20W
- Impedance
- 4Ω
- Range
- 85–13000Hz
- EBP †
- 142 · Leans vented
Size and mounting
- Diameter
- 70mm
- Cutout
- 63.8mm
- Depth
- 41.2mm
- Weight
- 0.36kg
Other published values
- Cms
- 0.61mm/N
- Power Peak
- 40
Sensitivity shows 81.5 dB, calculated from the T/S values. Dayton Audio publishes 85.0 dB, 3.5 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Dayton Audio lists
LF · Primary · 2.5″
- BL
- 3.1T·m
- Fs
- 109Hz
- Le
- 0.31mH
- Re
- 3.1Ω
- Sd
- 25cm²
- Cms
- 0.61mm/N
- Mms
- 4g
- Qes
- 0.77
- Qms
- 3.5
- Qts
- 0.63
- SPL
- 81.5dB
- Vas
- 0.5L
- Xmax
- 4mm
- Power
- 20W
- Impedance
- 4Ω
- Power Peak
- 40
- Sensitivity
- 85dB
- Low limit
- 85Hz
- Calculated sensitivity †
- 81.5dB
- High limit
- 13000Hz
- Manufacturer sensitivity
- 85dB
- Weight
- 0.36kg
- Diameter
- 70mm
- Depth
- 41.2mm
- Cutout
- 63.8mm
