Monacor TF1525/8 8Ω
LF DriverMedia
Auto-advancing
Overview
LF DriverTF series
Monacor
Monacor TF1525/8
Monacor TF1525/8 is a 15" 8 ohm LF driver rated at 250W RMS. The validated T/S data includes Fs 48Hz, Qts 0.49, Vas 148.4L, Xmax 4.5mm, sensitivity 96.6dB, plus 385cm³ Vd and 84 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
15"
Impedance
8Ω
RMS Power
250W
Sensitivity
96.6dB
98.0dBmanufacturer; using T/S-derived value (1.4dB delta).
EBP
84
Either alignment
Vd
385cm³
T/S Parameters
Valid
Fs48Hz
Qts0.49
Qes0.56
Qms3.4
Vas148.4L
Re5.2Ω
Le0.00mH
BL14.6Tm
Sd855cm²
Mms78g
Xmax4.5mm
SPL97dB
Power250W
Impedance8Ω
F Low40Hz
F High3000Hz
Voice Coil64mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Not enough T/S data
Missing Le
BASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Not enough T/S data
Missing Le
VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Not enough T/S data
Missing Le
00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.2kg
Diameter385.0mm
Overall Depth153.0mm
Cutout Diameter351.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Monacor
TF1525/8
15"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
100%
Similarity
£79.00
Celestion
TF1525
15"
Xmax4.5mm0%
Qts0.490%
BL14.6Tm0%
Vas148.4L0%
Qes0.560%
78%
Similarity
Jensen
BP15250-8
15"
Xmax3.4mm-24%
Qts0.51+3%
BL15.3Tm+5%
Vas133.1L-10%
Qes0.58+3%
77%
Similarity
P.Audio
15BMA-500B
15"
Xmax5mm+11%
Qts0.49-1%
BL17.2Tm+18%
Vas121.2L-18%
Qes0.52-8%
75%
Similarity
£145.52
Eighteen Sound
15W500
15"
Xmax4mm-11%
Qts0.52+5%
BL12.6Tm-14%
Vas189L+27%
Qes0.55-3%
74%
Similarity
P.Audio
15BMA-400B
15"
Xmax3.8mm-17%
Qts0.46-7%
BL16Tm+10%
Vas159.8L+8%
Qes0.49-13%
74%
Similarity
Monacor
TF1525E/4
15"
Xmax5.3mm+17%
Qts0.47-4%
BL17.8Tm+22%
Vas141.8L-4%
Qes0.53-6%
74%
Similarity
Monacor
TF1525E/8
15"
Xmax5.3mm+17%
Qts0.47-4%
BL17.8Tm+22%
Vas141.8L-4%
Qes0.53-6%
74%
Similarity
£90.00
Celestion
TF1525E
15"
Xmax5.3mm+17%
Qts0.47-4%
BL17.8Tm+22%
Vas141.8L-4%
Qes0.53-6%
73%
Similarity
Jensen
BS15N350A-8
15"
Xmax5.5mm+22%
Qts0.46-7%
BL15.2Tm+5%
Vas163.1L+10%
Qes0.49-13%
72%
Similarity
Peerless
FSL-1525R04-04
15"
Xmax5.6mm+24%
Qts0.49-1%
BL13.4Tm-8%
Vas115L-23%
Qes0.5-12%
70%
Similarity
Lavoce
FBASS15-20
15"
Xmax4.3mm-4%
Qts0.53+8%
BL12.8Tm-12%
Vas234.4L+58%
Qes0.57+1%
70%
Similarity
£95.00
Fane
SOVEREIGN 15-400LF
15"
Xmax4.6mm+2%
Qts0.57+16%
BL13.5Tm-7%
Vas210L+42%
Qes0.62+10%
