Overview
LF DriverK series
Monacor
Monacor K12H-100TC/8
Monacor K12H-100TC/8 is a 12" 8 ohm LF driver rated at 100W RMS. The validated T/S data includes Fs 56Hz, Qts 0.40, Vas 72L, Xmax 3mm, sensitivity 96.2dB, plus 159cm³ Vd and 118 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
12"
Impedance
8Ω
RMS Power
100W
Sensitivity
96.2dB
EBP
118
Vented alignment
Vd
159cm³
T/S Parameters
Valid
Fs56Hz
Qts0.40
Qes0.47
Qms2.5
Vas72.0L
Re5.5Ω
Le0.67mH
BL13.6Tm
Sd531cm²
Mms45g
Xmax3.0mm
SPL96dB
Power100W
Impedance8Ω
F Low50Hz
F High10000Hz
Voice Coil45mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.7kg
Diameter309.0mm
Overall Depth129.7mm
Cutout Diameter283.0mm
