Overview
LF DriverFTX series
Monacor
Monacor FTX0820/8
Monacor FTX0820/8 is a 8" 8 ohm LF driver rated at 200W RMS. The validated T/S data includes Fs 79Hz, Qts 0.28, Vas 13.1L, Xmax 4mm, sensitivity 95.2dB, plus 91cm³ Vd and 254 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
8"
Impedance
8Ω
RMS Power
200W
Sensitivity
95.2dB
94.0dBmanufacturer; using T/S-derived value (1.2dB delta).
EBP
254
Vented alignment
Vd
91cm³
T/S Parameters
Valid
Fs79Hz
Qts0.28
Qes0.31
Qms2.8
Vas13.1L
Re5.8Ω
Le0.62mH
BL14.6Tm
Sd227cm²
Mms23g
Xmax4.0mm
SPL95dB
Power200W
Impedance8Ω
F Low70Hz
F High5000Hz
Voice Coil50mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight4.1kg
Diameter225.0mm
Overall Depth123.0mm
Cutout Diameter187.0mm
