Overview
LF DriverAL series
Visaton
Visaton AL 170 - 8 OHM
Visaton AL 170 - 8 OHM is a 6.5" 8 ohm LF driver rated at 70W RMS. The validated T/S data includes Fs 38Hz, Qts 0.39, Vas 34L, Xmax 11mm, sensitivity 88.4dB, plus 146cm³ Vd and 88 EBP. bits tracks UK vendor pricing, price movement, datasheet links, simulator import data, and similar drivers, with a current best price of £151.14.
Size
6.5"
Impedance
8Ω
RMS Power
70W
Sensitivity
88.4dB
EBP
88
Either alignment
Vd
146cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
frequency response240 ptsp1medium
Curve provenanceInspect 1 traceHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
frequency response
Frequency response
240 plotted pointsMedium confidence1,249 selected pixels of 1,600
T/S Parameters
Valid
Fs38Hz
Qts0.39
Qes0.43
Qms3.9
Vas34.0L
Re5.6Ω
Le0.90mH
BL6.9Tm
Sd133cm²
Mms13g
Xmax11.0mm
SPL88dB
Power70W
Impedance8Ω
F High10000Hz
Voice Coil25mm
Flux Density1.10T
Pricing & availability
Price definitionsPrice movement
Other offers
1 vendorsoundimports
Updated 11 Sept 2026
Source: inc VAT
£150.31
inc VAT
Out of stock
Best current price
Updated 11 Sept 2026
wilmslowaudio
£151.14
inc VAT
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight1.2kg
Diameter170.0mm
Cutout Diameter150.0mm
