10-inch LF driver · NCP series · 400 W
Peerless NCP-1030R02-08 8Ω
8 Ω
No current price
- Fs
- 45Hz
- Xmax
- 9.3mm
- SPL
- 91dB
- Pe
- 400W
- BL
- 31.7T·m
- Vd
- 312cm³
- Qts
- 0.25
- Vas
- 21L
Peerless NCP-1030R02-08 is a 10-inch 8 ohm LF driver rated at 400 W RMS. The validated T/S data includes Fs 45 Hz, Qts 0.25, Vas 20.9 L, Xmax 9.3 mm, sensitivity 90.8 dB, plus 312 cm³ Vd and 180 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
The published T/S values agree with each other
Thiele/Small
- Fs
- 45Hz
- Qts
- 0.25
- Qes
- 0.25
- Qms
- 13.5
- Vas
- 20.9L
- Re
- 9.2Ω
- Le
- 1.25mH
Motor and cone
- BL
- 31.7T·m
- Sd
- 337cm²
- Mms
- 98g
- Xmax
- 9.3mm
- Vd †
- 312cm³
Power and response
- Sensitivity †
- 90.8dB
- Manufacturer sensitivity
- 87.4dB
- Power
- 400W
- Impedance
- 8Ω
- EBP †
- 180 · Leans vented
Size and mounting
- Weight
- 4.5kg
Other published values
- Cms
- 0.13mm/N
- Power Peak
- 500
Sensitivity shows 90.8 dB, calculated from the T/S values. Peerless publishes 87.4 dB, 3.4 dB apart.
† Calculated by bits from the published values
What this validation status means
Everything else Peerless lists
LF · Primary · 10″
- BL
- 31.7T·m
- Fs
- 45Hz
- Le
- 1.25mH
- Re
- 9.2Ω
- Sd
- 337cm²
- Cms
- 0.13mm/N
- Mms
- 98g
- Qes
- 0.25
- Qms
- 13.5
- Qts
- 0.25
- SPL
- 87.4dB
- Vas
- 20.9L
- Xmax
- 9.3mm
- Power
- 400W
- Impedance
- 8Ω
- Power Peak
- 500
- Weight
- 4.5kg
