Overview
LF DriverFTX series
Monacor
Monacor FTX0617/8
Monacor FTX0617/8 is a 6.5" 8 ohm LF driver rated at 150W RMS. The validated T/S data includes Fs 100Hz, Qts 0.74, Vas 7.3L, Xmax 3.5mm, sensitivity 91dB, plus 54cm³ Vd and 108 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
6.5"
Impedance
8Ω
RMS Power
150W
Sensitivity
91.0dB
92.0dBmanufacturer; using T/S-derived value (1.0dB delta).
EBP
108
Vented alignment
Vd
54cm³
T/S Parameters
Valid
Fs100Hz
Qts0.74
Qes0.93
Qms3.7
Vas7.3L
Re5.5Ω
Le0.27mH
BL6.6Tm
Sd154cm²
Mms12g
Xmax3.5mm
SPL91dB
Power150W
Impedance8Ω
F Low100Hz
F High6000Hz
Voice Coil44mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight2.3kg
Diameter189.0mm
Overall Depth93.0mm
Cutout Diameter150.0mm
