Overview
LF Driver
Dayton Audio
Dayton Audio APOLLO 18F
Dayton Audio APOLLO 18F is a 18" 8 ohm LF driver rated at 1200W RMS. The validated T/S data includes Fs 32Hz, Qts 0.40, Vas 287.7L, Xmax 10.6mm, sensitivity 95.5dB, plus 1272cm³ Vd and 76 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
18"
Impedance
8Ω
RMS Power
1200W
Sensitivity
95.5dB
EBP
76
Either alignment
Vd
1272cm³
Datasheet traces
Frequency and impedance curves traced from the manufacturer PDF.
15 degrees240 ptsp1medium
30 degrees204 ptsp1medium
45 degrees221 ptsp1medium
on-axis240 ptsp1medium
Curve provenanceInspect 5 tracesHide details
These plotted lines are Bits digitizations of manufacturer evidence, not new measurements. How provenance works
- Trace datasheet-response-trace-poc/v1
15 degrees
Frequency response
240 plotted pointsMedium confidence615 selected pixels of 770 - Trace datasheet-response-trace-poc/v1
30 degrees
Frequency response
204 plotted pointsMedium confidence371 selected pixels of 624 - Trace datasheet-response-trace-poc/v1
45 degrees
Frequency response
221 plotted pointsMedium confidence552 selected pixels of 686 - Trace datasheet-response-trace-poc/v1
on-axis
Frequency response
240 plotted pointsMedium confidence1,150 selected pixels of 1,150 - Trace datasheet-response-trace-poc/v1
impedance
Impedance response
240 plotted pointsMedium confidence1,309 selected pixels of 2,334
T/S Parameters
Valid
Fs32Hz
Qts0.40
Qes0.42
Qms9.0
Vas287.7L
Re6.5Ω
Le2.25mH
BL24.4Tm
Sd1200cm²
Mms194g
Xmax10.6mm
SPL96dB
Power1200W
Impedance8Ω
F Low30Hz
F High1000Hz
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Diameter462.0mm
Overall Depth193.0mm
Cutout Diameter414.0mm
Similar Drivers
Size stays fixed. Tune the T/S ranges to change what counts as a match, or add a specific driver to compare it directly.
Reference
Dayton Audio
APOLLO 18F
18"
Compare on
Matches sit inside every range. Size stays fixed automatically.
5 active T/S params, plus size. Pin a driver to open a side-by-side comparison.
12 matches
Compare a specific driver
Added drivers stay at the front of the list, whatever the ranges say.
91%
Similarity
£242.00
Precision Devices
PD.185C001
18"
Xmax10.5mm-1%
Qts0.4+1%
BL21Tm-14%
Vas302L+5%
Qes0.42+1%
89%
Similarity
£249.54
Beyma
18LEX1000ND
18"
Xmax11mm+4%
Qts0.39-3%
BL22Tm-10%
Vas260L-10%
Qes0.420%
88%
Similarity
£225.00
Beyma
18LEX1200FE
18"
Xmax11mm+4%
Qts0.38-5%
BL23.2Tm-5%
Vas277L-4%
Qes0.39-7%
87%
Similarity
£225.00
Beyma
18LEX1000FE
18"
Xmax11mm+4%
Qts0.38-5%
BL23.8Tm-3%
Vas250L-13%
Qes0.39-7%
86%
Similarity
£252.44
FaitalPRO
18HP1010
18"
Xmax9.8mm-8%
Qts0.40%
BL22Tm-10%
Vas240.1L-17%
Qes0.420%
85%
Similarity
BMS
18N840
18"
Xmax10mm-6%
Qts0.37-8%
BL23Tm-6%
Vas261L-9%
Qes0.4-5%
84%
Similarity
SB Audience
ROSSO-18SW650
18"
Xmax11.2mm+5%
Qts0.41+2%
BL20.6Tm-16%
Vas304.3L+6%
Qes0.44+5%
82%
Similarity
£274.00
B&C
18NBX100
18"
Xmax10mm-6%
Qts0.38-5%
BL24.8Tm+1%
Vas198L-31%
Qes0.4-5%
82%
Similarity
Fane
COLOSSUS PRIME 18XS
18"
Xmax12mm+13%
Qts0.39-4%
BL22.4Tm-8%
Vas257L-11%
Qes0.4-4%
81%
Similarity
£341.86
Eighteen Sound
18TLW3000
18"
Xmax12mm+13%
Qts0.41+2%
BL24.5Tm0%
Vas185L-36%
Qes0.420%
81%
Similarity
£255.00
Beyma
18PWB1000FE
18"
Xmax12.5mm+18%
Qts0.38-5%
BL25Tm+2%
Vas317L+10%
Qes0.4-5%
81%
Similarity
Monacor
POWERPROX18/8
18"
Xmax9.6mm-9%
Qts0.38-5%
BL24.4Tm0%
Vas189L-34%
Qes0.43+3%
