LF DriverCF series
Monacor
Monacor CF1840JD/8
Monacor CF1840JD/8 is a 18" 8 ohm LF driver rated at 1200W RMS. The validated T/S data includes Fs 37Hz, Qts 0.40, Vas 155L, Xmax 12.5mm, sensitivity 94.6dB, plus 1418cm³ Vd and 85 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
18"
Impedance
8Ω
RMS Power
1200W
Sensitivity
94.6dB
97.0dBmanufacturer; using T/S-derived value (2.4dB delta).
EBP
85
Either alignment
Vd
1418cm³
T/S Parameters
Valid
Fs37Hz
Qts0.40
Qes0.44
Qms4.4
Vas155.0L
Re5.3Ω
Le1.16mH
BL24.8Tm
Sd1134cm²
Mms217g
Xmax12.5mm
SPL95dB
Power1200W
Impedance8Ω
F Low30Hz
F High2500Hz
Voice Coil100mm
Pricing & availability
Price definitionsNo current price found
Pricing may appear after the next vendor refresh.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight11.6kg
Diameter460.0mm
Overall Depth220.0mm
Cutout Diameter414.0mm
