Overview
LF DriverAN series
Monacor
Monacor AN2775/8
Monacor AN2775/8 is a 2.5" 8 ohm LF driver rated at 20W RMS. The validated T/S data includes Fs 123Hz, Qts 0.96, Vas 3.6L, Xmax 2.3mm, sensitivity 89.7dB, plus 6cm³ Vd and 106 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
2.5"
Impedance
8Ω
RMS Power
20W
Sensitivity
89.7dB
84.0dBmanufacturer; using T/S-derived value (5.7dB delta).
EBP
106
Vented alignment
Vd
6cm³
Overall Parameters
Valid
Fs123Hz
Qts0.96
Qes1.17
Qms5.4
Vas3.6L
Re5.0Ω
Le0.07mH
BL3.1Tm
Sd28cm²
Mms3g
Xmax2.3mm
SPL90dB
Power20W
Impedance8Ω
F Low160Hz
F High20000Hz
Voice Coil20mm
Hybrid view: LF section is used for excursion/motor values, while frequency limits merge upper sections.
What this validation status meansPricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
Dimensions & Physical
Weight0.1kg
Diameter71.3mm
Overall Depth45.0mm
Cutout Diameter66.1mm
Driver Components
LFPrimary
2.5"Fs123 Hz
Qts0.96
Qes1.17
Qms5.4
Vas3.6 L
Re5.0 Ω
Le0.07 mH
BL3.1 Tm
Sd28 cm²
Mms3 g
Xmax2.3 mm
SPL90 dB
Power20 W
Impedance8 Ω
F Low160 Hz
F High20000 Hz
Voice Coil20 mm
Cms0.62
Power Peak40
Section dimensions
Weight100.0 kg
Diameter71.3 mm
Overall Depth45.0 mm
Mounting Depth45.0
Cutout Diameter66.1 mm
