2-inch compression driver · 75 mm voice coil · 100 W
Eighteen Sound ND2080 16Ω
500–20000 Hz
No price for delivery to the UK
- SPL
- 110dB
- Pe
- 100W
- Xover
- 800Hz
- Throat
- 50mm
- VC
- 75mm
Published graphs
Eighteen Sound ND2080 is a 2-inch 16 ohm compression driver rated at 100 W RMS. The source-backed specifications include sensitivity 110 dB, range from 500 Hz, to 20000 Hz, throat 50 mm. bits tracks vendor pricing and datasheet links from the same loudspeaker database.
Source-backed specifications
Motor and cone
- Voice coil
- 75mm
Power and response
- Sensitivity
- 110dB
- Power
- 100W
- Nominal power
- 100W
- Impedance
- 16Ω
- Min. impedance
- 10.2Ω
- Range
- 500–20000Hz
- Crossover
- 800Hz
- Throat
- 50mm
Size and mounting
- Diameter
- 131mm
- Depth
- 99mm
- Weight
- 3.4kg
Other published values
- Power Program
- 200
Everything else Eighteen Sound lists
HF · Primary · 2″
- SPL
- 110dB
- Power
- 100W
- Impedance
- 16Ω
- Sensitivity
- 110dB
- Low limit
- 500Hz
- Nominal power
- 100W
- Power Program
- 200
- High limit
- 20000Hz
- Throat
- 50mm
- Manufacturer sensitivity
- 110dB
- Min. impedance
- 10.2Ω
- Voice coil
- 75mm
- Crossover
- 800Hz
- Weight
- 3.4kg
- Diameter
- 131mm
- Depth
- 99mm
| Shop | Price | Against the lowest | Stock | Link |
|---|---|---|---|---|
Lean Business | £309.47 | Out of stock | Visit shop at Lean Business | |
Lean Audio | £441.72 | Back order | Visit shop at Lean Audio |
