6-inch passive radiator · SB16 series
SB Acoustics SB16PFC-00
No current price
Simulator support pending: 00 Simulator import needs complete passive-radiator parameters.
- Fs
- 22Hz
- Sd
- 124cm²
- Xmax
- –
- Mms
- 38g
- Vas
- 30L
- Qms
- 4.4
SB Acoustics SB16PFC-00 is a 6-inch passive radiator. The source-backed mechanical data includes Fs 22 Hz, Vas 30 L. bits tracks vendor pricing and datasheet links from the same loudspeaker database.
Partial source evidence
No automated T/S validation result is published for this record yet.
- Manufacturer page linked
- Datasheet linked
- Canonical units normalized for comparison
Thiele/Small
- Fs
- 22Hz
- Qms
- 4.4
- Vas
- 30L
Motor and cone
- Sd
- 124cm²
- Mms
- 38g
Size and mounting
- Weight
- 0.16kg
Other published values
- Cms
- 1.40mm/N
Everything else SB Acoustics lists
LF · Primary · 6″
- Fs
- 22Hz
- Sd
- 124cm²
- Cms
- 1.40mm/N
- Mms
- 38g
- Qms
- 4.4
- Vas
- 30L
- Weight
- 0.16kg
No current price found. Pricing may appear after the next vendor refresh.
