7-inch passive radiator · Hall of Fame series
Accuton P173
20–70 Hz
No current price
Simulator support pending: 00 Simulator import needs complete passive-radiator parameters.
- Fs
- 41Hz
- Sd
- 130cm²
- Xmax
- 10mm
- Mms
- 15g
- Vas
- 24L
- Qms
- –
Accuton P173 is a 7-inch passive radiator. The source-backed mechanical data includes Fs 41 Hz, Vas 24 L, Xmax 10 mm, plus 130 cm³ Vd. bits tracks vendor pricing and datasheet links from the same loudspeaker database.
Partial source evidence
No automated T/S validation result is published for this record yet.
- Manufacturer page linked
- Datasheet linked
- Canonical units normalized for comparison
- Vd can be derived from Sd and Xmax
Thiele/Small
- Fs
- 41Hz
- Vas
- 24L
Motor and cone
- Sd
- 130cm²
- Mms
- 15g
- Xmax
- 10mm
Power and response
- Range
- 20–70Hz
Size and mounting
- Diameter
- 173mm
- Cutout
- 145.6mm
- Depth
- 62mm
Other published values
- Cms
- 1.01mm/N
Everything else Accuton lists
LF · Primary · 7″
- Fs
- 41Hz
- Sd
- 130cm²
- Cms
- 1.01mm/N
- Mms
- 15g
- Vas
- 24L
- Xmax
- 10mm
- Low limit
- 20Hz
- High limit
- 70Hz
- Diameter
- 173mm
- Depth
- 62mm
- Cutout
- 145.6mm
No current price found. Pricing may appear after the next vendor refresh.
