Overview
LF DriverCrystalid series
Accuton
Accuton CL190-6-351
Accuton CL190-6-351 is a - 6 ohm LF driver rated at 120W RMS. The validated T/S data includes Fs 46Hz, Qts 0.37, Vas 25.4L, Xmax 4mm, sensitivity 89.8dB, plus 82cm³ Vd and 112 EBP. bits tracks vendor pricing, datasheet links, simulator import data, and similar drivers from the same loudspeaker database.
Size
-
Impedance
6Ω
RMS Power
120W
Sensitivity
89.8dB
EBP
112
Vented alignment
Vd
82cm³
T/S Parameters
Valid
Fs46Hz
Qts0.37
Qes0.41
Qms3.1
Vas25.4L
Re5.4Ω
Le0.17mH
BL10.3Tm
Sd206cm²
Mms28g
Xmax4.0mm
SPL90dB
Power120W
Impedance6Ω
F Low40Hz
F High3Hz
Voice Coil114mm
Pricing & availability
Price definitionsNo standard offers found
Check the manufacturer website for current pricing.
Use this driver
Open it in 00 Simulator, download it for your enclosure tool, or copy the specification values.
Files use canonical values. Required mechanical fields are derived only where the target format needs them.
WinISD
.wdr · WinISD driver editor
Native WinISD driver record with the required SI conversions.
Download for WinISDBASTA!
.bastaelement · BASTA! loudspeaker simulator
Native BASTA! element file using its documented SI-unit fields.
Download for BASTA!VituixCAD
.wdr · VituixCAD 2 Enclosure
A WinISD driver file that VituixCAD imports directly.
Download for VituixCAD00 Simulator
Direct import · Web app
Start a new enclosure simulation with this driver already loaded.
Open in 00 SimulatorCopy spec sheet
Plain text · Clipboard
Copy the available values as a clean label-and-value list.
