T/S Parameters
Valid
Fs29Hz
Qts0.31
Qes0.31
Qms15.3
Vas224.6L
Re3.8Ω
Le1.38mH
BL33.8Tm
Sd1642cm²
Mms508g
Xmax21.0mm
SPL97dB
Power2500W
Impedance6Ω
F Low25Hz
F High0Hz
Pricing & availability
Offers & B-stock
1 hidden from price comparisons
No standard offers found
Show offers & B-stock to include non-standard listings.
Dimensions & Physical
Weight21.8kg
Diameter549.9mm
Overall Depth263.9mm
Cutout Diameter503.7mm
Bolt Circle Diameter525.0mm
Similar Drivers
Keep size fixed, then add or remove T/S params to change the ranking and the comparison rows.
Reference
Eminence
NSW6021-6 21
21"
