T/S Parameters
Valid
Fs51Hz
Qts0.47
Qes0.51
Qms7.3
Vas67.9L
Re6.1Ω
Le1.45mH
BL14.1Tm
Sd507cm²
Mms51g
Xmax4.8mm
SPL95dB
Power500W
Impedance8Ω
F Low44Hz
F High3000Hz
Pricing & availability
Price movement
Other offers
2 vendorsleanbusiness
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£119.95
inc VAT
thomann
Updated 28 Apr 2026
Source: inc VAT · 20%
£139.00
inc VAT
Best current price
Updated 17 May 2026
bluearan
£105.00
Avg £121.32£16.32 below avg (-13.4%)
inc VAT
Dimensions & Physical
Weight5.4kg
Diameter305.6mm
Overall Depth135.9mm
Cutout Diameter281.2mm
Bolt Circle Diameter294.4mm
