T/S Parameters
Valid
Fs52Hz
Qts0.51
Qes0.58
Qms4.3
Vas61.4L
Re15.1Ω
Le1.33mH
BL15.1Tm
Sd345cm²
Mms25g
Xmax3.0mm
SPL94dB
Power250W
Impedance16Ω
F Low50Hz
F High3000Hz
Pricing & availability
No standard offers found
Check the manufacturer website for current pricing.
Dimensions & Physical
Weight3.1kg
Diameter256.8mm
Overall Depth101.1mm
Cutout Diameter231.9mm
Bolt Circle Diameter243.8mm
Similar Drivers
Keep size fixed, then add or remove T/S params to change the ranking and the comparison rows.
Reference
Eminence
BETA-10B 16-Ohm
10"
