T/S Parameters
Valid
Fs73Hz
Qts0.59
Qes0.68
Qms4.6
Vas17.7L
Re5.3Ω
Le0.44mH
BL7.8Tm
Sd210cm²
Mms17g
Xmax3.2mm
SPL94dB
Power125W
Impedance8Ω
F Low58Hz
F High5000Hz
Pricing & availability
Offers & B-stock
1 hidden from price comparisons
Price movement
Other offers
4 vendorsleanaudio
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£68.12
inc VAT
leanbusiness
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£68.12
inc VAT
leanaudio
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£76.15
inc VAT
thomann
Updated 17 May 2026
Source: inc VAT · 20%
£83.00
inc VAT
Best current price
Updated 17 May 2026
bluearan
£54.66
Avg £70.01£15.35 below avg (-21.9%)
inc VAT
Dimensions & Physical
Weight2.0kg
Diameter209.3mm
Overall Depth82.5mm
Cutout Diameter181.1mm
Bolt Circle Diameter196.8mm
