T/S Parameters
Valid
Fs50Hz
Qts0.59
Qes0.66
Qms5.2
Vas82.2L
Re5.3Ω
Le0.66mH
BL7.5Tm
Sd355cm²
Mms22g
Xmax3.2mm
SPL96dB
Power150W
Impedance8Ω
F Low57Hz
F High4000Hz
Pricing & availability
Offers & B-stock
1 hidden from price comparisons
Price movement
Other offers
3 vendorsbluearan
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£70.28
inc VAT
leanaudio
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£79.69
inc VAT
thomann
Updated 17 May 2026· 8Ω
Source: inc VAT · 20%
£102.00
inc VAT
Best current price
Updated 17 May 2026
leanbusiness
£63.00
Avg £78.74£15.74 below avg (-20.0%)
inc VAT
Dimensions & Physical
Weight2.0kg
Diameter256.8mm
Overall Depth99.1mm
Cutout Diameter231.9mm
Bolt Circle Diameter243.8mm
